We not only provide skid steer loaders, also independent R&D relative attachments for loaders, including backhoe, drill, trencher, sweeper, mixer, cutting machine, brush cutter, hydraulic breaker, dozer blade, 4 in 1 bucket, wood and grass grapple, pallet fork etc more than 100 kinds of attachments.
Can customized made to satisfy your special requirements.
Technical Parameters：
|
Rated operating capacity(kg) |
1200 |
|
Tipping load (kg) |
2400 |
|
Bucket capacity(m3) |
0.4-0.5 |
|
Hydraulic pump flow (L/min) |
100 |
|
Engine power (hp) |
80 |
|
Weight(kg) |
4000 |
|
Max travel speed (km/h) |
8/16 |
|
Grade ability |
20 |
|
Fuel/hyd. Oil capacity(L) |
85 |
Dimensions：
|
Skid Steer Loader |
TS80 |
|
A-Height to top of ROPS |
2160mm |
|
B-Ground clearance |
200mm |
|
C-Max．1ift height at hinge pin |
2920mm |
|
E-Length of under carriage |
1938mm |
|
F-Machine length without bucket |
2780mm |
|
G-Machine length with bucket |
3580mm |
|
H-Machine width |
1880mm |
|
I-Track width |
320mm |
|
D-Length of track on ground |
1500mm |
